LUNYEE 4040 Pro CNC-Fräsmaschine, verbesserte 3-Achsen-Ganzmetall-CNC-Graviermaschine
Pairs well with
|
Arbeitsbereich |
400 x 400 x 90 mm (15,75 x 15,75 x 3,54 Zoll) |
|
Laufwerkstyp |
Synchronriemenantrieb und Kugelumlaufspindel |
|
Steuerplatine |
4Achsen 5.0 GRBL 1.1f |
|
Schrittmotor |
Nema17 42 x 38 mm |
|
Schrittmotorantrieb |
A4988 |
|
Spindel |
52 mm, 100 W, 10000 U/min/500 W, 12000 U/min |
|
Leistung |
24 V 100 W/48 V 500 W |
|
Maximale Bewegungsgeschwindigkeit |
2000 mm/min |
|
Max. Prozessgeschwindigkeit |
2000 mm/min |
|
Maximale Beschleunigungsgeschwindigkeit |
300 mm/s² |
|
Genauigkeit |
±0,1 mm |
|
Endschalter |
Ja (x1, x2, Y1, Y2, Z1, Z2) |
|
Not-Aus |
Ja |
|
Z-Sonde |
Ja |
|
Software |
Kerze |
|
Laser |
Unterstützung Lasermodul mit |
|
Betriebssystem |
Windows XP/7/8/10 Linux |
|
Gesamtgröße der Maschine |
725*675*375 mm |
|
Maschinengewicht |
17 kg |
Optionen auswählen
Z-Axis Upgrade
Say goodbye to unsteady cutting, this 4040 pro cnc machine X-axis gantry features a thickened 60x40mm profile, while the Z-axis adopts a dual linear guide rail and ball screw design, enhancing stability and machining precision. The dual Y-axis setup and robust base frame provide strong support for your projects.
Specifically Designed for Woodworking
Equipped with Y-axis housing dust covers, the Lunyee 4040 Pro CNC router can effectively prevent dust and debris.Bottom-mounted LED lights can provide illumination, keeping the workspace clean and enhancing efficiency for various projects.
Steel-Core Belt Design for Smooth Operation
Our 4040 Pro steel-core belt system ensures smooth and quiet operation. It guarantees precise cutting on the XY axis with an accuracy of ±0.1mm, eliminating the need for constant adjustments. Additionally, we provide a complete set of V-cutting bits to effortlessly handle most tasks.
Upgraded Control Board
The 4040 Pro CNC router control board supports the addition of a laser module, air assist pump, offline controller, MPG, and a 4th axis. It also provides 52mm and 65mm spindle clamps, allowing seamless switching between different power spindles and trim routers.
User-Friendly Control System
The control box features an emergency stop button and a convenient home button, designed for beginner-friendly operation. The side-open design (front and rear magnetic dust shields) allows easy handling of larger materials, enhancing the overall user experience. All stepper motors are equipped with manual handwheels for effortless spindle or material positioning and adjustment.
Assembly Upgrade & Wide Compatibility
Major components of this CNC machine come pre-assembled with a step-by-step manual, allowing for easy setup in just 10-15 minutes. Compatible with the GRBL 1.1F control board, it supports software such as Easel, UGS, Candle, LightBurn, Fusion 360, and more, making it suitable for various CNC setups.
Large Engraving Area
The effective working area is 15.75” x 15.75” x 3.54” (400 x 400 x 90mm), providing ample space for daily woodworking and metalworking tasks, meeting the needs of various projects.
Supports various module combinations
While the standard spindle of the 4040Pro CNC router machine reaches a speed of 10,000 rpm with its 100 watts, it achieves 12,000 rpm with an optional 500-watt high-speed spindle. The powerful spindle ensures quiet and fast heat dissipation, making engraving smoother. It also provides 52mm and 65mm spindle clamps, allowing seamless switching between different power spindles、laser module and trim routers.
Specifications
| Model Name | LUNYEE 4040PRO |
| Work Area |
400 x 400 x 90mm (15.74 x 15.74 x 3.54 inch) |
| Overall Dimensions | 725 x 675 x 375mm (28.54 x 26.57 x 14.76 inch) |
| Control Board Compatibility | 4-axis 5.0 GRBL 1.1f |
| MCU | 32-Bit |
| Max Speed | 5000mm/min |
| Control Software | Software Based on GRBL Firmware, e.g. Fusion360, Easel, Candle, UGS, LaserGRBL, LightBurn |
| Body Material | Metal Frame & Hybrid Spoilboard |
| Accuracy | ±0.1mm |
| Motion System | Linear Guides：Z-HG15 Ball screws：Z-Φ12mm Synchronous belt drive：X, Y |
| Spindle Motor | 100W Spindle, 500W and 710W AC Spindle Motor (Optional) |
| Stepper Motor | NEMA 17, Stepper Motor |
| Safety | XYZ Limit Switch & Emergency Stop Switch |
| Power Supply | AC110/230V (Switch Power) |
| Net Weight | 17kg (37 lb) |
Support:
Email Support
One-year Warranty For Free
Compatible with GRBL-Base CAM/CNC Software
